8
Figure 1. Model 1069 rear panel
2.3 APPLICATION
In an example application, the VDSL2 CPE modem is placed in either
MxU environments or individual residents for delivering triple play ser-
vices including “fiber like” high-speed broadband service. Built-in
POTS/ISDN splitters allow for both data and voice to be broken out at the
CPE.
Figure 2. Model 1069 and VDSL DSLAM application
Eth
3
Eth
0
Eth
1
Eth
2
12 VD
C 1
A
POTS/ISDN
Power jack
Reset switch
Ethernet ports
(0-3)
VDSL twisted-pair
RJ-45 interface
POTS/ISDN twisted-pair
RJ-45 interface
