Operating Modes
Powerware 9125’s front panel indicates the UPS status through the UPS
indicators. Figure 30 shows the UPS front panel indicators and controls.
Normal Mode Indicator
Flashing
Unlit
Lit
Indicator Legend
Test/Alarm Reset Button
On Button
Off Button
Bypass Mode Indicator
Bar Graph Indicators
Alarm Indicators (see page 63)
Battery Mode Indicator
Figure 30. UPS Front Panel
