INSTALLATION
EATON Powerware
®
9125 Two-in-One UPS (2500/3000 VA) User’s Guide
S 164201374 Rev D
www.powerware.com
20
7.
Place the EBM cabinet upside down so that the right end of the
cabinet is accessible (see Figure 10).
Figure 10. Installing EBM Pedestals
8.
Align the pedestals with the screw holes on the end of the EBM
cabinet. Secure the pedestals with the screws provided in the
accessory kit.
9.
Carefully position the cabinets upright with the air vents at the top
(see Figure 11 or Figure 12).
Air Vents
Figure 11. Pedestals with Two Cabinets
