Paxar Monarch 9414 User Manual
Page 10
1-6 Getting Started
14. Plug the printer’s power supply cable (with the
straight end) into the socket on the back of the
printer.
15. Connect the serial cable to the printer’s serial
port.
16. If necessary, adjust the cables. Make sure all the
cables move freely through the openings in the
back of the tray. Use a cable tie to secure them.
17. Lift up the keypad/terminal with one hand and feed
the scanner cable connector through the notch as
shown.
Scanner
Cable
Pow er Cable
Serial Cable
