REMOTE LOCATOR ™ Should this set’s remote
control ever be misplaced, simply push the power
button on the set itself to activate the remote
locator system. The words “Locating Remote”
appear on the screen and the remote control beeps
– leading you right to it. Touching any key on the
remote deactivates the feature.
BACKLIT LED REMOTE CONTROL Makes it easy
to use all remote TV functions even in low light
conditions. No more fumbling with tiny buttons; just
press the glow-in-the-dark STATUS button and all
major function buttons light up.
UNIVERSAL TV/VCR/CABLE REMOTE Controls all
features and functions of this monitor/receiver with
direct menu access plus activates Smart Window
™
Picture-In-Picture with Action Freeze, Position and
Swap; and exclusive SmartSound
™ and SmartPicture ™
options. In addition, this remote controls all
important operating features and functions of
virtually all infrared VCRs, and on/off and channel
up/down on most cable converter/decoders.
(Remote #Y177ME )
TWO-TUNER PIP Now you can enjoy all the
benefits of Smart Window ™ PIP without a VCR! With
two separate tuners (and two separate tuner inputs)
you can tune to your favorite show with tuner one,
for example, while scanning other channels with
tuner two in the PIP window. The A/V inputs are
also available as PIP sources so all functions of
standard PIP are still accessible. The main and
secondary pictures may be swapped; position
secondary pictures in any screen corner; even freeze
the main picture information and put it into the inset
picture. In all cases, the main picture is provided with
its corresponding audio. A “size select” menu
function permits the viewer to reduce the size of the
inset picture by approximately 50%.
FRONT A/V JACKS For fast, easy connection of
external video sources (VCR, Camcorder, or Video
Games) nothing beats Front Audio/Video Input Jacks.
Simply plug connecting cables from the device into
the well-defined inputs and the sensor jacks
automatically place the large screen in the A/V mode,
ready to go.
• SURROUND SOUND JACKS
• SECOND S-VIDEO JACK
• AUDIO/VIDEO JACK PANEL (GR7D-23)
160° wide-angle screen/550 foot lamberts peak
brightness
Delta 77/78 lenses with curved faceplate
7" liquid-cooled, liquid-coupled tubes
181 total channel capability
Clearview video noise reduction
Random channel access
Programmable scan tuning
120-minute sleep timer
Auto programming
Channel Edit
Total remote “menu” format tuning
with multi-color on screen graphics
181 channel capability
4-way cursor directional control
One-button picture reset
Status recall
Mono/Stereo/SAP select
Cable/Normal select
Two 5.25" woofers
Two 2" tweeters
INTERNET ADDRESS: http://www.philipsmagnavox.com
p i c t u r e :
r e m o t e c o n t r o l :
a d d i t i o n a l
f e a t u r e s :
A / V j a c k p a n e l :
48 " Large Screen Television
with Two-Tuner PIP
7P4841C
UPC:
Product dimensions: 41"W x 53"H x 24.3"D
Product weight: lbs.
Carton dimensions: 45.4"W x 54.5"H x 28.8"D
Carton weight: lbs.
Master pack: 1
Carton Contains: 48" Large Screen TV, Backlit Universal
TV/VCR/CBL Remote Control w/ Batteries, Operating
Instructions, Warranty Information
Printed in U.S.A.
©1997 Philips Consumer Electronics Co.
A Division of Philips Electronics North America Corp.
Specifications subject to change without notice.
Visual Communications, Philips Consumer Electronics Co.
dbx ® is a registered trademark of dbx, Inc., Sunnyvale, CA.
Remote Locator, SmartScreen, Smart Window, SmartSound, SmartPicture,
SmartMute, SmartSurf, and Incredible Stereo are trademarks of Philips Consumer
Electronics Company.
2 Lines per picture width. 600 based on EIA measurement procedures
PIP AUDIO Allows you to enjoy the audio portion
of the telecast selected for the Smart Window ™ inset
along with the audio portion of the main picture
telecast or in place of it.
SMARTPICTURE ™ W/ PERSONAL
PREFERENCE A touch of the SmartPicture ™ button
on the remote control provides the option of
selecting one of five preset positions, video game,
sports, movies, custom, or weak signal, to enhance
enjoyment. Select the desired option and all
important picture elements are instantly adjusted to
optimize viewing pleasure while input selection, PIP
functions, and other performance specifications are
customized for your viewing convenience.
• CHANNEL LABEL
• ADVANCED HELP MENU
•
SMARTSURF ™
• SMARTCLOCK ™
• SMARTMUTE ™
• EASY FIRST TIME SET-UP
• ON-SCREEN CLOCK WITH SLEEP TIMER AND
ALARM TIMER
• TRILINGUAL ON-SCREEN DISPLAY
• AUTO PROGRAMMING
• CLOSED CAPTION
• CHANNEL REMINDER DISPLAY
• CHANNEL EDIT
• 25-WATT DBX ® HI-FI STEREO SOUND
SYSTEM WITH FOUR SPEAKERS
• SMARTSOUND ™
• TRUE SURROUND SOUND
• INCREDIBLE STEREO
™
• BASS BOOST
• ON-SCREEN VOLUME BAR
c o n v e n i e n c e :
MAGNABRITE LENSES By moving the red,
green, and blue guns closer to the view screen
more consistent edge-to-edge brightness and
contrast become a reality. Add the advantage of
Delta 77/78 optics and the focal length of the
guns is dramatically reduced producing crisp,
well-defined large screen images and slim
cabinet design.
DIGITAL COMB FILTER Get greater picture
resolution for sharper, clearer, more detail-
perfect color picture reproduction. Capable of
delivering 800 lines of horizontal resolution
2 ,
this set exceeds the maximum clarity of the 330
lines of horizontal resolution delivered by
broadcast television and easily supports the
demands of DVD, web browsers, and other
advanced high resolution video media (through
S-Video inputs).
DIGITAL CONVERGENCE Designed to meet
the demands of curved CRT faceplates and
short focal length lenses, Digital Convergence
brings with it the accuracy of digital technology
for flawless convergence of red, green, and blue
guns and a superb picture with no colored
haloes.
LUMINANCE TRANSIENCE IMPROVEMENT
(LTI)
A new generation of edge enhancement
technology applied directly to the video
processing circuitry creates a remarkable increase
in clarity and sharpness at the point of transition
from dark to light areas of the video image.
When coupled with other recent advancements,
LTI produces a picture so sharp and well defined
that it rivals that of a direct-view TV.
DYNAMIC BLUE STRETCH Developed to
refine the white areas of the video image
produced by large screen TVs, Dynamic Blue
Stretch applies blue highlights to the white areas
extending their brilliance resulting in a brighter,
clearer picture.
BLACK STRETCH Special circuitry has been
incorporated into this television receiver to
enhance the darker portions of the picture for
added realism and overall picture quality.
s o u n d :
