59
MAINTENANCE
Brake Fluid
Hand Brake
The master cylinder is
located on the left handle-
bar. Maintain the fluid
level 6 mm below the top
edge of the master cylin-
der. Do not overfill.
1. Position the vehicle on a level surface. Make sure the handlebars are
straight.
2. View the fluid level through the indicator window (eye) on the top
of the master cylinder. The eye will appear dark when the fluid level
is full. When fluid is low, the eye will be clear.
3. Add the recommended fluid as needed. Do not overfill.
Foot Brake
1. Position the vehicle on a level surface.
2. The brake fluid reservoir is located either under the seat or near the
foot brake. View the fluid level in the master cylinder.
3. Maintain the fluid level between the minimum and maximum
marks. Do not overfill.
Master
Cylinder
Indicator
Window
