103
SPECIFICATIONS
Jetting Chart
Clutching Chart
Trail Boss 330
Driving System Type
Automatic PVT (Polaris Variable Transmission)
Shift Type
Side Lever (F/N/R)
Gear Reduction, Reverse
3.05:1
Gear Reduction, Forward
2.68:1
Drive Ratio, Final
3.64:1
Drive Chain
520 O-Ring
Tires/Pressure, Front
23 x 7-10 (4 psi/27.6 kPa)
Tires/Pressure, Rear
22 x 11-10 (3 psi/20.7 kPa)
Front Suspension
MacPherson strut with 8.2" (21 cm) travel
Rear Suspension
Progressive rate with 10.5" (26.7 cm) travel
Shock Adjustment
CAM
Brakes, Front and Rear
Single-Control Hydraulic Disc
Brake, Auxiliary
Foot-Activated Hydraulic Disc, Rear Wheel
Brake, Parking
Hydraulic lock, all wheel
Headlight
2 Dual Beam 30w/30w
Taillights
12V 8.26W
Brake Light
12V 26.9W
Battery
12V 14AH
Indicators
High Beam/Turn Signals/High Temp/Neutral/
Reverse
ALTITUDE
Meters (Feet)
AMBIENT TEMPERATURE
Below 40° F
(Below 5° C)
40°F and above
(5°C and above)
0-1800 (0-6000)
127.5
122.5
1800-3700 (6000-12000)
120
115
Altitude
Meters (Feet)
Shift
Weight
Drive Clutch
Spring
Driven Clutch
Spring
Helix/Spring/
Setting
0-1800
(0-6000)
10RHF
5632282
Blue/Gray
7042202
Black
7041782
40°
5131446
2+2
1800-3700
(6000-12000)
20-40
5631356
Blue/Gray
7042202
Black
7041782
40°
5131446
2+2
