Peavey PCX-U302 User Manual
Page 7
desired device. Make sure the unbalanced
level switch is in the proper position before
applying power.
c. Balanced
Output:
Connect the male XLR connector into the
balanced output connector on the back of the
receiver. Connect the other end of the cable
into the “Mic/Balanced” input of the desired
device. The characteristics of the 3-pin XLR
connector are shown below in figure 4.
Fig. 4
7
GND PIN 1
PIN 3
PIN 2
