20

Pelco Manual C306M-K (4/05)

AZIMUTH ZERO

Azimuth is the pan angle from 0° to 359°. Azimuth zero is the programmed 0° point that is
normally set to magnetic north. Once programmed, on-screen pan position (azimuth) and
compass readings are based on the set azimuth zero point.

To set azimuth zero:

1.

Program preset 95 (28). The main menu appears.

2.

Position the cursor (>) beside Other.

3.

Press the Iris Open button to enter the Other menu.

4.

Position the cursor (>) beside Az/El/Direction.

5.

Press the Iris Open button to enter the Az/El/Direction menu.

6.

Position the cursor (>) beside Set Azimuth Zero.

7.

Press the Iris Open button. The programming menu for Set Azimuth Zero appears on
the monitor.

8.

Use the joystick to pan the Esprit unit to the desired azimuth zero (0° point) position.

9.

Press the Iris Open button to set the azimuth zero position.

Other Menu

Park Time

0

Pan/Scan Spd

7

Power Up

Default

Pat length

6 min

Spd Profile

50 MPH wind



Exit

Az/El/Direction

Set Azimuth Zero

Az/El

Az/El Line

Direction

Direction Line

Disp Duration

Exit

MAIN MENU



EXIT
