14 Pelco Manual C306M-K (4/05)
OPERATION
POWER-UP DISPLAY
When the Esprit system is powered up or reset, the selected protocol, revision number, and
other information is displayed on the monitor. For example, the screen might show the fol-
lowing information:
The information displayed depends on the selected protocol
(C, D, or P) and the menu selection for power-up mode.
(Refer to the
Power-Up Mode in the Programming section).
The information remains on the monitor until the dome is
moved.
HOW TO OPERATE YOUR ESPRIT INTEGRATED POSITIONING
SYSTEM
Operation How to Control
Pan and Tilt Move joystick left/right and up/down.
Scanning
Stop Scan Call preset 96.
Random Scan Call preset 97.
Frame Scan Call preset 98.
Auto Scan Call preset 99.
Presets Refer to the documentation supplied with the controller.
Patterns Refer to the documentation supplied with the controller.
Zones Refer to the Programming section and to the
documentation supplied with the controller.
For more information refer to Operating Notes.
OPERATING NOTES
ENVIRONMENTAL RANGE
The operating temperature ranges from a minimum of -40°F (-40°C) to a maximum of 122°F
(50°C) for sustained system operation or 140°F (60°C) absolute maximum. The entire unit
can de-ice and be operational in two hours from a temperature of -13°F (-25°C). The thermo-
statically controlled heater consumes 10 watts and cycles on at 70°F (21°C) and off at 85°F
(29°C), while the window defroster runs continuously and consumes 2.5 watts.
PAN AND TILT FUNCTIONS
Controller Pan Tilt
Type (Capability, 360° Continuous (Viewing Range, +40° to -90°)***
Pan Rotation)**
Fixed speed Speed determined by Speed determined by controller
controller
*Variable speed 0.5 to 40° per second, 0.5 to 20° per second, depending
depending on joystick position on joystick position
*Turbo Mode 100° per second Does not affect the tilt speed
*Preset Mode 100° per second 30° per second
*50 mph wind speed profile.
** If manual limit stops are set, “Pan Limit” appears on your monitor when a limit stop is
reached. This does not apply to scan limit stops.
*** When the system reaches the upper limit, “Tilt Limit” appears on your monitor.
PELCO ESPRIT 1.20
CONFIGURE DONE
D Address 1
P Address 2
