PCAN-USB Hub – User Manual
3
Contents
1 Introduction 5
1.1 Properties at a Glance 5
1.2 System Requirements 6
1.3 Scope of Supply 7
2 Installing the Software and the Adapter 8
3 Connectors on the Adapter 11
3.1 Upstream Port (USB Cable) 11
3.2 Power (Voltage Supply) 11
3.3 CAN 12
3.3.1 Supplying External Devices via the CAN
Connector
13
3.4 RS-232 15
3.5 USB Ports (Downstream) 15
3.6 Cabling 16
3.6.1 Termination 16
3.6.2 Example of a Connection 16
3.6.3 Maximum Bus Length 17
4 Operation 18
4.1 Status LEDs 18
4.2 Unplugging the Hub 19
4.3 Distinguishing Several PCAN-USB Hub 19
5 Using the Software 20
5.1 CAN Monitor PCAN-View for Windows 20
5.1.1 Receive/Transmit Tab 22
5.1.2 Trace Tab 24
5.1.3 PCAN-USB Tab 25
