Panasonic DPX153U - Manual (Page 14)

q
w
q
w
CQ-DP133U/DP103U/DPX153U
E
N
G
L
I
S
H
18
27
Anti-Theft System
Install Removable Face Plate
ᕡ Slide the left side of the removable face plate in
place.
ᕢ Press the right end of the removable face plate
until “click” is heard.
Cautions:
• This face plate is not waterproof. Do not expose it to water or excessive moisture.
• Do not remove the face plate while driving your car.
• Do not place the face plate on the dashboard or nearby areas where the temperature rises to high level.
• Do not touch the contacts on the face plate or the main unit, since this may result in poor electrical con-
tacts.
• If dirt or other foreign substances get on the contacts, wipe them off with a clean and dry cloth.
• Do not apply a strong downward force onto the face plate and do not put anything on it while it is open, or
it might be damaged.
This unit is equipped with a removable face plate. Removing this face plate makes the radio totally inoperable.
Place the Removable Face
Plate into Case
ᕡ Switch off the power of the unit.
ᕢ Remove the removable face plate. ( ➡ page 26)
ᕣ Gently press the bottom of the case and open
the cover. Place the face plate into the case and
take it with you when you leave the car.
w
q
u Removable face plate case
Plastic tab
Cutout
E
N
G
L
I
S
H
17
26
Installation Guide
(Continued)
CQ-DP133U/DP103U/DPX153U
1
2
3
4
To Remove the Unit
Switch off the power of the unit.
Remove the removable face plate.
q Press [ ] . The removable face plate will
be opened.
w Push the face plate to either the right or
left.
e Pull it out toward you.
Remove the Trim Plate i with a screwdriver.
q Insert the Dismounting plate o along
the grooves on both sides of the main
unit until “click” is heard.
w Pull out the unit while pushing the plates
further inside.
Remove the unit pulling with both hands.
Contact
q Press
i Trim Plate
Screwdriver
o Dismounting plate Insert the tab
end in the
outer groove.
“ Click”
Insert
Pull out
w
