Transistors
Publication date: June 2007 SJC00391AED
This product complies with the RoHS Directive (EU 2002/95/EC).
2SC4627G
Silicon NPN epitaxial planar type
For high-frequency amplification
■ Features
• Optimum for RF amplification of FM/AM radios
• High transition frequency f
T
• SS-Mini type package, allowing downsizing of the equipment and
automatic insertion through the tape packing
■ Absolute Maximum Ratings T
a
= 25°C
Parameter Symbol Rating Unit
Collector-base voltage (Emitter open) V
CBO
30 V
Collector-emitter voltage (Base open) V
CEO
20 V
Emitter-base voltage (Collector open) V
EBO
3 V
Collector current I
C
15 mA
Collector power dissipation P
C
125 mW
Junction temperature T
j
125 °C
Storage temperature T
stg
−55 to +125 °C
Parameter Symbol Conditions Min Typ Max Unit
Collector-base voltage (Emitter open) V
CBO
I
C
= 10 µA, I
E
= 0 30 V
Emitter-base voltage (Collector open) V
EBO
I
E
= 10 µA, I
C
= 0 3 V
Base-emitter voltage V
BE
V
CB
= 6 V, I
E
= −1 mA
720 mV
Forward current transfer ratio * h
FE
V
CB
= 6 V, I
E
= −1 mA 65 160 
Transition frequency f
T
V
CB
= 6 V, I
E
= −1 mA, f = 200 MHz
450 650 MHz
Reverse transfer capacitance C
re
V
CB
= 6 V, I
E
= −1 mA, f = 10.7 MHz
0.8 1.0 pF
(Common emitter)
Power gain PG V
CB
= 6 V, I
E
= −1 mA, f = 100 MHz
24 dB
Noise figure NF V
CB
= 6 V, I
E
= −1 mA, f = 100 MHz 3.3 dB
■ Electrical Characteristics T
a
= 25°C ± 3°C
Rank C
h
FE
65 to 160
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
2. *: Rank classification
■ Package
• Code
SSMini3-F3
• Marking Symbol: U
• Pin Name
1. Base
2. Emitter
3. Collector
