Panasonic PT-D5000ELS User Manual

Multiple terminals, Dimensions, Based projector

Please contact Panasonic or your dealer for a demonstration.

http://panasonic.net/avc/projector

For more information about Panasonic projectors ––

Weights and dimensions shown are approximate. Specifications are subject to change without notice.

This product may be subject to export regulations.

An application has been filed for trademark rights, or trademark rights have been granted,

for PJLink in Japan, United States of America and other countries and area.

XGA is trademark of International Business Machines Corporation.

All other trademarks are the property of their respective trademark owners. Projection Images simulated.

DLP, DLP logo and DLP Medallion logo are trademarks or registered trademarks of Texas Instruments.

All information included here is valid as of May 2009.

PT-D5KE1 Printed in Japan.

JQA-1617

EC98J2010

Specifications

Optional accessories

Projection distance

50"

80"

100"

150"

200"

300"

400"

500"

600"

With ET-DLE150

1.3-2.0:1

1,344mm

4.5'

2,183mm

7.2'

2,742mm

9.0'

4,140mm

13.6'

5,537mm

18.2'

8,333mm

27.4'

11,129mm

36.6'

13,924mm

45.7'

16,720mm

54.9'

1,967mm

6.5'

3,177mm

10.5'

3,983mm

13.1'

6,000mm

19.7'

8,016mm

26.3'

12,049mm

39.6'

16,082mm

52.8'

20,115mm

66.0'

24,148mm

79.3'

Screen size (4:3)

Diagonal


size

min.

max.

With supplied lens

1.8-2.4:1

1,785mm

5.9'

2,895mm

9.5'

3,635mm

12.0'

5,485mm

18.0'

7,335mm

24.1'

11,035mm

36.3'

14,735mm

48.4'

18,435mm

60.5'

22,135mm

72.7'

2,376mm

7.8'

3,840mm

12.6'

4,816mm

15.9'

7,256mm

23.9'

9,696mm

31.9'

14,576mm

47.9'

19,456mm

63.9'

24,336mm

79.9'

29,216mm

95.9'

min.

max.

With ET-DLE250

2.4-3.7:1

2,361mm

7.8'

3,826mm

12.6'

4,803mm

15.8'

7,244mm

23.8'

9,686mm

31.8'

14,568mm

47.8'

19,451mm

63.9'

24,334mm

79.9'

29,217mm

95.9'

3,777mm

12.4'

6,090mm

20.0'

7,633mm

25.1'

11,489mm

37.7'

15,344mm

50.4'

23,056mm

75.7'

30,768mm

101.0'

38,480mm

126.3'

46,192mm

151.6'

min.

max.

With ET-DLE350

3.7-5.6:1

3,713mm

12.2'

6,023mm

19.8'

7,562mm

24.9'

11,411mm

37.5'

15,259mm

50.1'

22,956mm

75.4'

30,653mm

100.6'

38,350mm

125.9'

46,047mm

151.1'

5,681mm

18.7'

9,170mm

30.1'

11,496mm

37.8'

17,312mm

56.8'

23,127mm

75.9'

34,758mm

114.1'

46,389mm

152.2'

58,020mm

190.4'

69,651mm

228.6'

min.

max.

With ET-DLE450

5.5-8.9:1

5,525mm

18.2'

9,020mm

29.6'

11,351mm

37.3'

17,177mm

56.4'

23,004mm

75.5'

34,656mm

113.8'

46,309mm

152.0'

57,961mm

190.2'

69,614mm

228.4'

With

ET-DLE055

0.8:1

808mm

2.7'

1,322mm

4.4'

1,664mm

5.5'

2,519mm

8.3'

3,375mm

11.1'

—

—
—

—

8,912mm

29.3'

14,438mm

47.4'

18,123mm

59.5'

27,333mm

89.7'

36,544mm

119.9'

54,966mm

180.4'

73,387mm

240.8'

91,809mm

301.3'

110,231mm

361.7'

min.

max.

Lens

Lamp

Ceiling mount bracket

Zoom lens

ET-DLE150
(1.3–2.0:1)

Zoom lens

ET-DLE250
(2.4–3.7:1)

Zoom lens

ET-DLE350
(3.7–5.6:1)

Zoom lens

ET-DLE450
(5.5–8.9:1)

Fixed-focus lens

ET-DLE055
(0.8:1)

ET-PKD56H (for high ceilings)

ET-PKD55S (for low ceilings)

Replacement lamp unit

ET-LAD60

ET-LAD60W (twin pack)

Filter

Replacement filter unit

ET-ACF100

ET-PKD56H

ET-PKD55S

Power supply
Power consumption

DLP

™

chip Panel size

Display method

Pixels

Lens

PT-D5000ES

PT-D5000ELS

Lamp
Screen size
Brightness*

Centre-to-corner uniformity*

Contrast*

Resolution

Scanning

DVI-D

frequency RGB

(YC

)

S-Video/Video

Optical axis shift
Keystone correction range
Installation
Terminals*

DVI-D IN

RGB 1/YP

RGB 2/YP

VIDEO IN

S-VIDEO IN

SERIAL IN

SERIAL OUT

REMOTE 1 IN

REMOTE 1 OUT

REMOTE 2 IN

LAN

Power cord length
Cabinet material
Dimensions PT-D5000ES
(W x H x D) PT-D5000ELS
Weight*

PT-D5000ES

PT-D5000ELS

Operating temperature
Operating humidity
Supplied accessories

220–240 V AC 50/60 Hz

600 W (670 VA)

(Eco standby mode*

: 0.3 W, Standby mode normal: 9 W. Both with fan stopped.)

0.7˝ diagonal (4:3 aspect ratio)

DLP

™

chip x 1, DLP

™

system

786,432 (1,024 x 768) x 1, total of 786,432 pixels

Powered zoom/focus lenses (1.8–2.4:1), F 1.7–2.0, f 25.6–33.8 mm

Optional powered zoom/focus lenses

240 W UHM lamps (x 2) (dual-lamp system)

50–600 inches (50–200 inches with the ET-DLE055), 4:3 aspect ratio

5,000 lumens (dual-lamp)

90 %

1,000:1 (full on/full off)

1,024 x 768 pixels

(Input signals that exceed this resolution will be converted to 1,024 x 768 pixels.)

Horizontal: 15–91 kHz, Vertical: 50–85 Hz, Dot clock: 162 MHz or lower
Horizontal: 15–91 kHz, Vertical: 50–85 Hz, Dot clock: 150 MHz or lower

525i (480i), 625i (576i), 525p (480p), 625p (576p), 750 (720)/60p,

750 (720)/50p, 1035/60i, 1125 (1080)/60i, 1125 (1080)/50i, 1080/25p, 1080/24p,

1080/24sF, 1080/30p, 1080/60p, 1080/50p

Horizontal: 15.75/15.63 kHz, Vertical: 50/60 Hz,

(NTSC, NTSC4.43, PAL, PAL60, PAL-N, PAL-M, SECAM)

Vertical: +50 % (powered), horizontal: ±10 % (powered)

Vertical: ±40° (±30° with the ET-DLE055)

Ceiling/floor, front/rear

DVI-D 24-pin

BNC x 5

D-sub HD 15-pin

BNC

Mini DIN 4-pin

D-sub 9-pin (RS-232C compliant)

D-sub 9-pin

M3 jack
M3 jack

D-sub 9-pin

RJ-45 for network connection, 10Base-T/100Base-TX, compliant with PJLink™

3.0 m (9´10˝ )

Molded plastic

498 mm x 175 mm*

x 440 mm*

(19-19/32˝ x 6-7/8˝ *

x 17-5/16˝ *

) (with supplied lens)

498 mm x 175 mm*

x 432 mm (19-19/32˝ x 6-7/8˝ *

x 17˝) (without lens)

Approx. 16.0 kg (35.3 lbs) (with supplied lens)

Approx. 15.2 kg (33.5 lbs) (without lens)

0–45°C (32–113°F)

20–80 % (no condensation)

Power cord, Wireless/wired remote control unit,

Batteries for remote control (x 2), Wire rope

*1 In Eco standby mode, LAN-based network functions such as the standby ON function will not operate.

*2 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.

*3 The HD/SYNC and VD inputs do not accept the tri-level sync signal.

*4 With leg at shortest position.

*5 Including the supplied lens.

*6 Average value. May differ depending on models.

1. Do not install the projector in locations that are subject to excessive water, humidity, steam, or oily smoke. Doing so may result in fire, malfunction, or electric shock.
2. The projector uses a high-voltage mercury lamp that contains high internal pressure. This lamp may break, emitting a large sound, or fail to illuminate,
due to impact or extended use.
3. The projector uses a high-wattage lamp that becomes very hot during operation. Please observe the following precautions.
• Never place objects on top of the projector while it is in operation.
• Make sure there is an unobstructed space of 500 mm (1.64 feet) or more around the projector's exhaust openings.
• Do not stack projector units directly on top of one another for the purpose of multiple (stacked) projection. When stacking projector units, be sure to
provide the amount of space indicated between them. These space requirements also apply to installation where only one projector unit is operating at
one time and the other unit is used as a backup.
• If the projector is placed in a box or enclosure, temperature of the air surrounding the projector must be between 0 ˚C (32 ˚F) and 40 ˚C (104 ˚F). Also
make sure the projector's intake and exhaust openings are not blocked. Take particular care to ensure that hot air from the exhaust openings is not
sucked into the intake openings.
* Even when the ambient temperature near the intake opening is 40 ˚C (104 ˚F) or lower, an accumulation of hot air inside the cabinet may cause the
protective circuit to activate and shut down the projector. Please give ample consideration to the design with regard to ambient temperature conditions.
4. If the projector is to be operated continuously 24 hours a day, use the dual-lamp optical system's alternating lamp operation (lamp changer) function.
The projector cannot be operated continuously 24 hours a day in dual-lamp mode. Allow a minimum of two hours per day of non-operation time per
lamp if using the dual-lamp mode.
5. The lamp replacement cycle duration becomes shorter if the projector is operated repeatedly for short periods.
• The length of time that it takes for the lamp to break or fail to illuminate varies greatly depending on individual lamp characteristics and usage conditions.
• The brightness of the lamp will gradually decrease with use.

NOTES ON USE

Communicate more effectively

with crisp, vibrant images

DLP

™

Based Projector

PT-

D5000ES

PT-

D5000ELS

XGA

5,000

Multiple terminals

LAN Terminal Video Input S-Video Input RGB 1 Input RGB 2 Input DVI-D (HDCP Compatible) Input
Remote 1 Input and Output Remote 2 Input Serial Input Serial Output

Dimensions

unit: mm (inch)

498 (19-19/32)

)

-7

)
