Congratulations
on your new purchase! With proper use, this
dependable product will provide years of
enjoyment. Please fill in the information below.
(Serial number is on tag on back of VCR.)
Before Using
• Date of Purchase
• Dealer Purchased From
• Dealer Address
• Dealer Phone No.
• Model No.
PV-V4525S
• Serial No.
Head Cleaning
• Important Safeguards •
Accessor
ies • Head Cleaning • Loading Batteries • Pr
e
v
ent
T
a
pe Erasur
e
• Specif
ications • Record/Playb
ack T
ime
- 3 -
Video Head Clog Sensor
Screen-right appears during
play if clogging is detected.
To remove screen, press PLAY.
• Use “dry” type head
cleaning cassette only.
(Part No. NV-TCL30PT is recommended.)
• Follow cleaning tape instructions carefully.
Excessive use of tape can shorten head life.
• If head clog symptoms persist, contact your
nearest servicenter by visiting our Web Site
(p. 12).
Old or damaged tapes may clog heads.
V I DEO HEADS MAY
NEED CLEAN I NG
PLEASE I NSERT HEAD
CLEAN I NG CASSETTE
OR REFER TO MANUAL
END : PLAY
RF Coaxial Cable
LSJA0418
Batteries 2 “AA”
Remote Control
EUR7723KA0
Accessories
To order accessories, call toll free
1-800-332-5368.
Loading the Batteries
Battery replacement caution
• Do not mix old and new batteries.
• Do not mix alkaline with manganese batteries.
1) Open cover.
3) Close cover.
2) Insert batteries
as marked.
Prevent Accidental Tape Erasure
To record again. Break off the tab to
prevent recording.
Record Tab
Screw driver
Cover the hole
with cellophane
tape.
Only use tapes with the mark in this unit.
Record/Playback Time
SP
(Standard Play)
2 Hours
40 Minutes
2 Hours
6 Hours 8 Hours
SLP
(Super Long Play)
Type of Video Cassette
Tape Speed
Setting
T180 T160 T120
3 Hours
9 Hours
Digital Auto Picture
Automatically controls the video output signal for
less noise depending on the tape condition.
Digital Auto Tracking
Continuously analyzes the signal and adjusts for
optimum picture quality.
Manual Tracking Control
(to reduce picture noise)
Use during Playback and Slow Motion mode to
reduce picture noise.
Press CH (TRACKING)
/ on the remote
control or on the VCR until the picture clears up.
To return to Auto Tracking, press POWER off,
then on again a few seconds later.
V-Lock Control (to reduce picture jitter)
In Still mode, CH (TRACKING) / operate as a
V-Lock control.
Features for a Quality Picture
R
R
R
R R
R
R
R
Use soft, dry cloth or dusting attachment of a
vacuum to remove dust from all cabinet vent
holes. You may moisten cloth with non-abrasive,
antistatic cleaner/ polisher.
Caution:
Alcohol and various solvents could damage finish.
Cleaning the VCR
Note: Designs and specifications are subject to
change without notice.
Power Source: 120 V AC, 60 Hz
Power Consumption: Power On
Approx. 14 W
Power Off
Approx. 0.9 W
Video Signal: EIA Standard NTSC color
Video Recording 4 rotary heads helical
System: scanning system
Audio Track: 1 track (Normal)
2 channel (Hi-Fi Audio Sound)
Tuner
Broadcast Channels: VHF 2 ~ 13, UHF 14 ~ 69
CABLE Channels:
Midband A ~ I (14 ~ 22)
Superband J ~ W (23 ~ 36)
Hyperband AA ~ EEE
(37 ~ 64)
Lowband A-5 ~ A-1 (95 ~ 99)
Special CABLE channel 5A (01)
Ultraband 65 ~ 94, 100 ~ 125
Operating
Temperature:
5 °C ~ 40 °C (41 °F ~ 104 °F)
Operating Humidity: 10 % ~ 75 %
Weight:
2.56 kg (5.6 lbs.)
Dimensions: 360 (W) x 89 (H) x 226 (D) mm
14-3/16” (W) x 3-1/2” (H) x
8-7/8” (D) inch
Specifications
