Polycom RMX 1500 Hardware Guide
1-17
RMX 1500 Rear Panel LEDs
RTM IP 1500 LEDs
The following LEDs appear on the RTM IP 1500:
Table 1-8 RTM IP 1500 LEDs
Component
LED
Name
LED Color Indication
LAN LEDs (1-2) LNK Green ON with an active network
connection, flickers with Packet
activity.
1 Gb Amber ON with a 1Gb online
connection, flickers with Packet
activity.
MNG LED LNK Green ON with an active network
connection, flickers with Packet
activity.
1 Gb Amber ON with a 1Gb online
connection, flickers with Packet
activity.
MNG B LED LNK Green ON with an active network
connection, flickers with Packet
activity.
1 Gb Amber ON with a 1Gb online
connection, flickers with Packet
activity.
Shelf LED LNK Green ON with an active network
connection, flickers with Packet
activity.
100 Amber ON when the active network is
10/100Mb, flickers with Packet
activity.
