06 Controls & Displays
English
Player (front)
Illustration shows the PDV-LC20.
Player (rear)
Illustration shows the PDV-LC20. The PDV-20 has audio and video outputs only.
AUDIO
IN/OUT
VIDEO
IN/OUT
DC IN 9.8V
+
–
Analog audio input/output,
and optical digital output
DC IN jack
Composite video input/output,
and S-Video output
Î
DISC COVER
2
OPEN
5
OPEN
Slide to open the disc cover
Remote control sensor
Power indicator
