14
Installation
Installing the housing mount frame
Attach the housing mount frame (supplied) to the rotary arm of the main unit.
 Attach the housing mount frame to the rotary arm as shown in the figure below. The screws must be installed together with
the flat washers and spring washers (supplied).
· Using the supplied Allen key, install the frame securely to prevent looseness in the four places where the screws are used.
Rotary arm
Allen key
Housing mount frame
