Connectors
DC Input
Locking or latching 4-pin Mini DIN Receptacle. The vendor P/N is H.C.E.
MD00027 or equivalent.
Description Pin Pin Description
+12VDC 1 3 +12VDC
GND 2 4 GND
Shield Shield
Video Input
15 pin D-subminiature connector. The vendor P/N is Aces 85314-1500 or
equivalent.
Description Pin Pin Description
Red Video 1 9 NC
Green Video 2 10 Logic Ground
Blue Video 3 11 NC
NC 4 12 SDA (DDC1/2B)
Logic Ground 5 13 H-sync
Red Video Ground 6 14 V-sync
Green Video Ground 7 15 SCL (DDC2B)
Blue Video Ground 8
Audio Port
Stereo mini-jack. The vendor p/n is Touke TC38-102-7
Description Pin Pin Description
L-Audio 1 4 NC
R-Audio 2 5 Ground
NC 3
Touch Port
9 pin D-subminiature connector.
Description Pin Pin Description
DCD 1 2 DSR
RXD 3 4 RTS
TXD 5 6 CTS
DTR 7 8 RI
Logic Ground 9
