Video Modes
The Planar D6015TM Medical Monitor will support 25 video timing modes
which were preset at the factory. Those modes not supported will cause the
monitor to go into power-saving mode. Once a mode is optimized, there is no
need to make any further adjustment as long as the VGA mode remains
unchanged. These specifications are subject to change without notice.
Mode
Horiz.
Freq.
(kHz)
Vert.
Freq.
(Hz)
Pixel
Freq.
(MHz)
H/V
Sync.
polarity
Comment
Mode
ID No.
640x400
31.469
70.087
25.175
-/+
VGA-400 Graphic
101
640x400
37.861
85.080
31.500
-/+
VESA-400 Graphic
102
720x400
31.469
70.087
28.322
-/+
VGA-400 Text
103
720x400
37.927
85.039
35.500
-/+
VESA-400 Text
104
640x400
24.830
56.420
21.050
-/-
NEC PC98-400
105
640x400
31.500
70.150
25.197
-/-
NEC PC98-400
106
640x350
31.469
70.087
25.175
+/-
VGA-350
107
640x350
37.861
85.080
31.500
+/-
VESA-350
108
640x480
31.469
59.940
25.175
-/-
VGA-480
109
640x480
35.000
66.670
30.240
-/-
APPLE MAC-480
110
640x480
37.861
72.809
31.500
-/-
VESA-480
111
640x480
37.500
75.000
31.500
-/-
VESA-480-75Hz
112
640x480
43.269
85.008
36.000
-/-
VESA-480-85Hz
113
800x600
35.156
56.250
36.000
+/+
SVGA
114
800x600
37.879
60.317
40.000
+/+
VESA-600
115
800x600
48.077
72.188
50.000
+/+
VESA-600-72Hz
116
800x600
46.875
75.000
49.500
+/+
VESA-600-75Hz
117
800x600
53.674
85.061
56.250
+/+
VESA-600-85Hz
118
832x624
49.730
74.550
57.283
-/-
APPLE MAC-800
119
1024x768
48.363
60.004
65.000
-/-
XGA
120
1024x768
53.964
66.132
71.644
+/+
COMPAC-XGA
121
1024x768
56.476
70.069
75.000
-/-
VESA-768
122
1024x768
60.023
75.029
78.750
+/+
VESA-768-75Hz
123
1024x768
60.240
75.020
80.000
-/-
APPLE MAC-768
124
1024x512
34.380
60.005
46.7568
-/-
SPECIAL
125
