Operations Manual (OM700-02) 15
OSD Main Menu
To access the OSD Main Menu, briefly press the Power button (see Figure 8).
The following screen appears:
MAIN MENU
BASIC SETTING
POSITION
AUTO-ADJUST
COLOR TEMP.
MISCELLANEOUS
RESET
ADJ KEY TO START
Figure 10: The OSD Main Menu
The control functions are grouped into five categories as shown on the Main
Menu in Figure 10. Continue pressing the up and down Function buttons
( and ) to scroll through the menu items. Use the Adjustment buttons
( and ) to enter the sub-menu of each function group. Each item is
described below.
Main Menu
BASIC SETTING Change the contrast, brightness, video level, gamma, etc.
POSITION Change display size, position, clock and phase, etc.
AUTO-ADJUST Automatically adjust the picture quality and alignment. It is
recommended you use this function in Windows or similar
environments (this function does not work in the interlaced
modes).
COLOR TEMP. Control the display colors.
MISCELLANEOUS Control audio volume and OSD position, and provide information
on display modes.
RESET Set display parameters to the factory set default values.
EXIT Exit OSD Menu.
Basic Setting
CONTRAST Adjust the contrast level of the display.
BRIGHTNESS Adjust the brightness level of the display.
VIDEO LEVEL Select the matching input signal voltage level (0.7Vpp or 1.0Vpp).
GAMMA Select a suitable color representation.
FRAME Select one of 64 border colors to show when display is not in full-
screen size. (Not available in all modes.)
TO MAIN MENU Return to Main Menu.
