The display controls – Planar VitalScreen D6015TM;TS User Manual
Page 17
Operations Manual (OM700-02)
13
The Display Controls
Located on the front of the Planar D6015TM Series Medical Monitor are five
buttons for operating the monitor and accessing the functions on the On-Screen
Display (OSD).
Button
1. Function select up
2. Function select down
3. Adjustment increase
4. Adjustment decrease
5. Power ON/OFF
6. Power LED
(LED: off, on, or flashing)
Figure 8: Monitor Display Controls
