– 44 –
Connector signals
∑ VIDEO IN
HD SDI (DIGITAL) BNC k 2, active through
SD SDI IN (DIGITAL) BNC k 2, active through
SD SDI SPARE BNC k 1
HD REF IN BNC k 2, loop-through with 75 ≠ termination switch
SD REF IN BNC k 2, loop-through with 75 ≠ termination switch
∑ VIDEO OUT
HD SDI OUT (DIGITAL) BNC k 3
HD SDI MONITOR OUT BNC k 1
(DIGITAL) (SUPER)
SD SDI OUT (DIGITAL) BNC k 2
SD SDI MONITOR BNC k 1
(DIGITAL) (SUPER)
VIDEO OUT (ANALOG) BNC k 3
HD REF OUT BNC k 1
SD REF OUT BNC k 1
WFM BNC k 1, Waveform output, 75 ≠ .
∑ TIME CODE
TIME CODE IN XLR k 1
TIME CODE OUT XLR k 1
∑ AUDIO IN
AUDIO IN (DIGITAL) BNC k 4, CH1/2, CH3/4, CH5/CH6, CH7/CH8,
AES/EBU format
AUDIO IN (ANALOG) XLR k 4, CH1, CH2, CH3, CH4
CUE IN XLR k 1
∑ AUDIO OUT
AUDIO OUT (DIGITAL) BNC k 4, CH1/2, CH3/4, CH5/CH6, CH7/CH8,
AES/EBU format
AUDIO OUT (ANALOG) XLR k 4, CH1, CH2, CH3, CH4
CUE OUT XLR k 1
MONITOR XLR k 2
HEADPHONES (FRONT) 1 ⁄
4 q phone
