Additional information 13
81
En
Specifications
Amplifier section
Maximum Output Power (1 kHz, THD 10.0 %, 6 Ω )
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 W/channel
Continuous Power Output (DIN 1 kHz, THD 1 %, 8 Ω )
Front. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130 W + 130 W
Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130 W
Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . 130 W + 130 W
Surround back . . . . . . . . . . . . . . . . . . . . . . 130 W + 130 W
Continuous Power Output (DIN 1 kHz, THD 1 %, 6 Ω )
Front. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150 W + 150 W
Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150 W
Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . 150 W + 150 W
Surround back . . . . . . . . . . . . . . . . . . . . . . 150 W + 150 W
Rated Power Output (20 Hz to 20 kHz, 0.09 %, 8 Ω )
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110 W+110 W
Rated Power Output (20 Hz to 20 kHz, 0.09 %, 6 Ω )
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130 W+130 W
Audio Section
Input (Sensitivity/Impedance)
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .335 mV/47 k
Ω
Frequency Response (LINE). . . . . . .5 Hz to 100 000 Hz dB
Output (Level/Impedance)
REC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 335 mV/2.2 k Ω
Tone Control
BASS . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±6 dB (100 Hz)
TREBLE . . . . . . . . . . . . . . . . . . . . . . . . . . ±6 dB (10 kHz)
LOUDNESS. . . . . . . . . . . +4 dB / +2 dB (100 Hz/10 kHz)
(at volume position –40 dB)
Signal-to-Noise Ratio (IHF, short circuited, A network)
LINE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103 dB
Signal-to-Noise Ratio
[DIN (continuous rated power output/50 mW)]
LINE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92 dB/65 dB
Composite Video / S-Video Section
Input (Sensitivity/Impedance) . . . . . . . . . . . . . . . .1 Vp-p/75 Ω
Output (Level/Impedance) . . . . . . . . . . . . . . . . . . .1 Vp-p/75 Ω
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . .65 dB
Frequency Response . . . . . . . . . . . . . . . . . . . .5 Hz to 10 MHz
Component Video Section
Input (Sensitivity/Impedance) . . . . . . . . . . . . . . . .1 Vp-p/75 Ω
Output (Level/Impedance) . . . . . . . . . . . . . . . . . . .1 Vp-p/75 Ω
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . .65 dB
Frequency Response . . . . . . . . . . . . . . . . . . .5 Hz to 100 MHz
FM Tuner Section
Frequency Range . . . . . . . . . . . . . . . . . 87.5 MHz to 108 MHz
Usable Sensitivity . . . . . . .Mono: 13.2 dBf, IHF (1.3 µV/75
Ω )
50 dB Quieting Sensitivity . . . . . . . . . . . . . . . Mono: 20.2 dBf
Stereo: 38.6 dBf
Sensitivity (DIN) . . . . . . . . . . . . . . . .Mono: 1.1 µV (S/N 26 dB)
Stereo: 50 µV (S/N 46 dB)
Signal-to-Noise Ratio . . . . . . . . . . . . Mono: 73 dB (at 85 dBf)
Stereo: 70 dB (at 85 dBf)
Signal-to-Noise Ratio (DIN). . . . . . . . . . . . . . . . . Mono: 62 dB
Stereo: 58 dB
Distortion . . . . . . . . . . . . . . . . . . . . . . . . Stereo: 0.5 % (1 kHz)
Alternate Channel Selectivity . . . . . . . . . . . .60 dB (400 kHz)
Stereo Separation . . . . . . . . . . . . . . . . . . . . . . . .40 dB (1 kHz)
Frequency Response . . . . . . . . . . . . . 30 Hz to 15 kHz ±1 dB
Antenna Input . . . . . . . . . . . . . . . . . . . . . . . 75
Ω unbalanced
AM Tuner Section
Frequency Range . . . . . . . 531 kHz to 1602 kHz (9 kHz step)
530 kHz to 1700 kHz (10 kHz step)
Sensitivity (IHF, Loop antenna) . . . . . . . . . . . . . . . . 350 µV/m
Selectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 dB
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 dB
Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Loop antenna
Miscellaneous
Power Requirements. . . . . . . . . . . . AC 110 V/120 V to 127 V/
220 V/230 V to 240 V, 50 Hz/60 Hz
Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . .450 W
In standby . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.65 W
Dimensions . . . . . . 420 mm (W) x 173 mm (H) x 465 mm (D)
Weight (without package). . . . . . . . . . . . . . . . . . . . . . . 15.3 kg
Furnished Parts
Setup microphone (for Auto MCACC setup). . . . . . . . . . . . . 1
AA/IEC R6P dry cell batteries . . . . . . . . . . . . . . . . . . . . . . . 2
Remote control unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
AM loop antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FM wire antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Power cords . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Antenna adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
These operating instructions
Note
• Specifications and the design are subject to possible
modifications without notice, due to improvements.
Cleaning the unit
• Use a polishing cloth or dry cloth to wipe off dust and
dirt.
• When the surface is dirty, wipe with a soft cloth
dipped in some neutral cleanser diluted five or six
times with water, and wrung out well, and then wipe
again with a dry cloth. Do not use furniture wax or
cleansers.
• Never use thinners, benzine, insecticide sprays or
other chemicals on or near this unit, since these will
corrode the surface.
