Controls and displays 04
23
En
15 Input source buttons
Press to select an input source.
16 VIDEO/GAME INPUT
See Connecting a component to the front panel inputs on
page 16.
17 USB interface
Connect a USB audio device for playback (see Using the
USB interface on page 33).
18 MCACC SETUP MIC jack
Use to connect the supplied microphone.
19 SYSTEM SETUP
Press to access the System Setup menu (see page 37).
20 RETURN
Press to confirm and exit the current menu screen.
21 TONE
Press this button to access the bass and treble controls,
which you can then adjust with the
MULTI JOG dial
(page 32).
22 TUNING/STATION
Use to find radio frequencies and to select preset
stations (page 35).
23 TUNER EDIT
Use with the MULTI JOG dial to memorize and name
stations for recall (page 35).
24 SPEAKERS
Use to change the speaker system (page 52).
Operating range of remote control unit
The remote control may not work properly if:
• There are obstacles between the remote control and
the receiver’s remote sensor.
• Direct sunlight or fluorescent light is shining onto the
remote sensor.
• The receiver is located near a device that is emitting
infrared rays.
• The receiver is operated simultaneously with another
infrared remote control unit.
DOW N
30
30
7 m
DOW N
