PC / DVI Timing Table
Mode
No.
Mode
Name
Resolution
H. Freq
(KHZ)
V. Freq
(HZ)
H. Polarity
V. Polarity
Pixel
CLK
(MHZ)
Hor.
Total
Hor.
Display
H. Back
Porch
Hor.
Sync
Width
Ver..
Total Ver.
Display
V. Back
Porch
Ver.
Sync
Width
1
VGA 60HZ
640*480
31.469
59.941
-
-
25.175 800 640 48 96 525 480 33 2
2
MAC VGA
640*480
35.000
66.667
-
-
30.24 864 640 96 64 525 480 39 3
3
VGA 75HZ
640*480
37.5
75.0
-
+
31.5 840 640 120 64 500 480 16 3
4
US TEXT
720*400
31.469
70.087
-
-
28.322 900 720 54 108 449 400 35 2
5
STB
768*576
31.250
50
-
-
29.75 952 768 124 32 625 576 29 13
6
SVGA
60HZ
800*600
37.879
60.317
+
+
40.0 1056 800 88 128 628 600 23 4
7
SVGA
75HZ
800*600
46.875
75.0
+
+
49.5 1056 800 160 80 625 600 21 3
8
XGA 60HZ
1024*768
48.363
60.004
-
-
65.0 1344 1024 160 136 806 768 29 6
9
XGA 70HZ
1024*768
56.476
70.069
-
-
75.0 1328 1024 144 136 806 768 29 6
10
WSGA
1280*768
47.708
60
-
-
80 1676 280 198 136 795 768 23 3
11
WSGA
1360*768
47.712
60.000
+
+
85 1792 1360 256 112 795 768 18 6
HDMI / HDCP Timing
Mode
No.
Mode Name Resolution
1 480i
2 480p
3 720p
4 1080i
