Connections & applications, Interface i – Planar XP37W User Manual
Page 14
V37EMBB-UD3_HDMI+ATSC 2005/12/15
上午
10:26
13
VIDEO DEVICE
(ex. DVD Player or Set-top Box…)
Connections & Applications
* How to connecting Video Device via HDMI ?
This can be applied only if there is the HDMI Output connector on the external device.
* How to connecting Video Device via D-SUB ?
Note: No sound connector is needed for an HDMI to HDMI connection.
Interface I
HDMI
D-SUB
AUDIO IN
VIDEO L R HDMI
Y Pb
Pr L
R
HDMI to HDMI Cable
PC
