C1. Rectangular window:
Apply top flashing tape. Cut two pieces of flashing tape
long enough to go across the top of the window and
EXTEND
ONE
THE
#
Apply top flashing tape. /N
window, DO NOT allow the side flashing tape to extend higher
than the top tape will cover.
D. Fold down top flap
$
$
&YUFSJPS
%
& E. Apply flashing tape to diagonal cuts. Cut
PIECES
Note: Be sure to overlap the top
corners (4E).
&
5
SECURING THE WINDOW
A. Install a #10 x 3-1/2" corrosion resistant wood
screw
Note: Minimum 1-1/4" embedment into the
wall framing is required.
5A
#10 x 3-1/2"
corrosion
resistant
wood screw
6
INSTALLATION CLIP METHOD
A. Fasten the window to the opening BY
CORROSION
Note: DO NOT shim above the window. For masonry openings use
two 3/16” x 1-1/2” masonry screws per clip. Pre-drill the masonry
before attempting to drive the screws in.
INTERIOR
6A
Note: If installing the window using installation
clips, proceed to Step 6 - Installation Clip Method.
Proceed to Step 7.
