APPENDIX C
PATTON MODEL 2715
FACTORY REPLACEMENT PARTS
AND ACCESSORIES
Patton Model # Description
2715/CM/UI .....................V.35 to E1 Converter (V.35 M/34 Male,
UI)
10 - 09F...........................6 Foot Control Port Cable, 25 mm to
DB9F
08055DCUI......................Universal Input Power Supply
10-CISCO-V35FT-1 .........Cable, V35 (M/34) Female To LFH60
Male
07M2715 .........................User Manual
APPENDIX D
PATTON MODEL 2715
INTERFACE PIN ASSIGNMENTS
RJ-48C E1 Network Interface
(RJ-48S Female Modular Jack)
Pin # Signal
1 RX Data (TIP)
2 RX Data (RING)
4 TX Data (TIP)
5 TX Data (RING)
