APPENDIX A
PATTON MODEL 2715
SPECIFICATIONS
Network Data Rate:
2.048 Mbps
Network Connector:
RJ-48C
Nominal Impedance:
120 ohm (75 ohm available when using
Patton Model 460 Balun)
DTE Interface:
V.35 (DCE Orientation) on Male M/34
Line Coding:
Selectable AMI or HDB3
Line Framing:
G.703 (Unframed) or G.704/G.732
(Framed)
CAS Multiframing:
Selectable On or Off
CRC-4 Multiframing:
Selectable On or Off
Clocking:
Internal, External, or Receive Recover
DTE Data Rates:
64, 128, 192, 256, 384, 512, 640, 768,
1024, 1280, 1536, 1600, 1920, 1984,
2048 kbps
Time Slot Rate:
64 kbps
DS0 Start Position:
Arbitrary
DS0 Mapping Position:
Contiguous or Arbitrary
Diagnostics:
V.54 Loopback; V.52 Patterns: 511,
2047, and QRSS
Indicators:
Power, Transmit Data, Receive Data,
Alarm, Loss of Sync, Test Mode, Error
Configuration:
8-Position DIP Switch and RS-232
Control Port
Power Supply:
100-240VAC, 50-60Hz, 0.4A
Humidity:
Up to 90% non-condensing
Temperature:
0 to 70
o
C
Dimensions:
9.0 x 5.3 x 2.0 cm (3.5”L x 2.1”W x
0.78”H)
APPENDIX B
PATTON MODEL 2715
CABLE RECOMMENDATIONS
The Patton Model 2715 has been performance tested by Patton
technicians using twisted-pair cable with the following characteristics:
Wire Gauge
Capacitance
Resistance
19 AWG
83nf/mi or 15.72 pf/ft.
.0163 Ohms/ft.
22 AWG
83nf/mi or 15.72 pf/ft.
.0326 Ohms/ft.
24 AWG
83nf/mi or 15.72 pf/ft.
.05165 Ohms/ft.
To gain optimum performance from the Model 2715 , please keep
the following guidelines in mind:
•
Always
use twisted pair wire—this is not an option.
• Use twisted pair wire with a capacitance of 20pf/ft or less.
• Avoid twisted pair wire thinner than 26 AWG (i.e. avoid AWG
numbers higher than 26)
• Use of twisted pair with a resistance greater than the above
specifications may cause a reduction in maximum distance obtain-
able. Functionality should not be affected.
• Many environmental factors can affect the maximum distance
obtainable at a particular site. Use the above data rate/distance
table as a
general guideline only.
Model 2703B Distance Table - Km (Miles)
Data Rate
Wire Gauge
(kbps)
.7mm (22)
.5mm (24)
2048
1.2 (.76)
1.5 (.95)
