8 EN
Connect GPS antenna
To receive signal from satellites, connect the
supplied GPS antenna to your car and the
system.
1
Connect the supplied GPS antenna to the
system fi rst.
2
Stick the other end of the GPS antenna to
a surface for signal reception.
Connect Radio antenna
If your car has built-in radio antenna, connect it
to the radio antenna of the system for better
radio signal.
1
Connect the radio antenna to the car
antenna.
Mount into the dashboard
Note
Check wire connection before you mount the unit into •
a car.
1
Take off the trim plate of the car.
2
Screw off the host car audio.
3
Fix the mounting brackets to CID3685
with screws (supplied by the car
manufacturer).
4
Fix the unit to the dashboard with screws
(supplied by the car manufacturer).
5
Attach the trim plate.
6
Reconnect the negative terminal of the car
battery.
