12- ENG D24938
IMPORTANT: The outlet being used
must be installed and grounded in
accordance with all local codes and
ordinances.
2. Make sure the outlet being used
has the same configuration as
the grounded plug. DO NOT
USE AN ADAPTER. See
illustration.
3. Inspect the plug and cord before
each use. Do not use if there
are signs of damage.
4. If these grounding instructions
are not completely understood,
or if in doubt as to whether the
compressor is properly
grounded, have the installation
checked by a qualified
electrician.
Risk of Electrical
Shock. IMPROPER
GROUNDING CAN RESULT IN
ELECTRICAL SHOCK.
Do not modify the plug provided. If
it does not fit the available outlet,
a correct outlet should be installed
by a qualified electrician.
Repairs to the cord set or plug
MUST be made by a qualified
electrician.
GROUNDING
INSTRUCTIONS
Risk of Electrical
Shock. In the
event of a short circuit, grounding
reduces the risk of shock by
providing an escape wire for the
electric current. This air
compressor must be properly
grounded.
The portable air compressor is
equipped with a cord having a
grounding wire with an appropriate
grounding plug (see following
illustrations).
1. The cord set and plug with this
unit contains a grounding pin.
This plug MUST be used with a
grounded outlet.
INSTALLATION
HOW TO SET UP YOUR
UNIT
Grounding Pin
Grounded
Outlets
Plug
Location of the Air Compressor
● Locate the air compressor in a
clean, dry, and well ventilated
area.
● Place on a solid surface to
prevent rocking or tipping.
● The air compressor should be
located at least 12" away from
the wall or other obstructions
that will interfere with the flow of
air.
● The air filter must be kept clear
of obstructions which could
reduce air flow to the air
compressor.
● The air compressor requires
fresh air flow for proper cooling.
DO NOT ALLOW THE
COMPRESSOR TO GET WET.
