Services Screen
This screen is displayed when the Edit Service List button on the Access Control
screen is clicked.
Figure 36: Access Control - Services
Data - Services Screen
Available Services
Available Ser-
vices
This lists all the available services.
"Delete" button
Use this to delete any Service you have added. Pre-defined
Services can not be deleted.
Add New Service
Name
Enter a descriptive name to identify this service.
Type
Select the protocol (TCP, UDP, ICMP) used to the remote
system or service.
Start Port
For TCP and UDP Services, enter the beginning of the range of
port numbers used by the service. If the service uses a single
port number, enter it in both the "Start" and "Finish" fields.
Finish Port
For TCP and UDP Services, enter the end of the range of port
numbers used by the service. If the service uses a single port
number, enter it in both the "Start" and "Finish" fields.
ICMP Type
For ICMP Services, enter the type number of the required
service.
Buttons
Delete
Delete the selected service from the list.
