3.1.1 CONFIGURATION SWITCH SET “S1”
The eight DIP switches on pack S1 set data rate, clock source,
async/sync mode and carrier control method. Factory default settings
are summarized in Figure in the table below. Descriptions of all
possible S1 switch settings, including the Patton factory default
settings, are found on on pages 4 and 5.
S1-1 through S1-4: Data Rate Setting
Switches S1-1 through S1-4 are set in combination to determine
the asynchronous and synchronous data rate for the Model 1045RC.
Model 1045RC:
S1-1 S1-2 S1-3 S1-4 Setting
Off Off On Off 32.0 kbps
Off On Off Off 56.0 kbps
On Off Off Off 64.0 kbps
S1-5 and S1-6: Clock Source
Switches S1-5 and S1-6 are set in combination to determine the
transmit clock source for the Model 1045RC.
S1-5 S1-6 Setting
On On Internal transmit clock
Off On Receive recover clock
On Off External transmit clock
S1-7: Carrier Control Method
5
The setting for switch S1-7 determines whether the carrier is
“constantly on” or “controlled by RTS”. This setting allows for operation
in switched carrier, multipoint and/or hardware handshaking
applications.
S1-7 Setting
Off Constantly on
On Controlled by RTS
S1-8: V.52 and V.54 Diagnostic Test
To reset the V.54 circuit, set switch S1-8 to the “ON” position, then
back to the “OFF” position.
S1-8 Setting
Off Enable (Normal Operation)
On Test Disabled
3.1.2 CONFIGURATION SWITCH SET “S2”
The eight DIP switches on pack S2 set RTS/CTS delay, word
length, extended signaling rate, async/sync mode and remote test
initiation. Factory default settings are summarized in the table below.
Descriptions of all possible S1 switch settings, including the Patton
factory default settings, are found on on pages 6 and 7.
6
S1 SUMMARY TABLE
Position Function Factory Default
S1-1 Data Rate Off
S1-2 Data Rate On
S1-3 Data Rate Off
S1-4 Data Rate Off
S1-5 Clock Source On
S1-6 Clock Source On
S1-7 Carrier Control Off Constantly On
S1-8 V.52/V.54 Tests Off Enable
56 Kbps
Internal
}
}
S2 SUMMARY TABLE
Position Function Factory Default
S2-1 RTS/CTS Delay On
S2-2 RTS/CTS Delay On
S2-3 Word Length Off
S2-4 Word Length Off
S2-5 Extended Signaling Off -2.5% to +1%
S2-6 Async/Sync Off Sync
S2-7 DTE Control of LAL On Enable
S2-8 DTE Control of RDL On Enable
10 bits
}
7 ms
}
