Powerware Ferrups FE/QFE 500VA User Manual
Page 48
External Bypass Switch Installation
42
Powerware
®
FERRUPS FE/QFE UPS (500 VA–18 kVA) Installation Guide
:
Rev A www.powerware.com
60 Hz 208 or 480 Source/240 Vac Input - 120/240 Vac Output (with Transformer)
Figure 14. FE 4.3–18 kVA UPS with External Bypass Switch
Table 19. Minimum Recommended Circuit Breakers for 240 Vac
Charger
4.3 kVA
5.3 kVA
7 kVA
10 kVA
12.5 kVA
18 kVA
Standard
20
25
35
50
70
100
10A
20
30
35
60
70
100
20A
20
35
35
60
80
110
