17” CDT Color Monitor 107B7
75
5.12 Movement of unit with base
• Base must have non-marring, non-staining feet.
• Unit must tilt up and down with no “Stick / Slip”.
• Base must provide sufficient friction to hold unit in desired position after adjusting tilt.
5.13 Label
• Regulatory label / Carton label should follow Philips requirement.
• Detail documents refer to Philips Engineering Reference Book.
5.14 Product Dimensions / Weight
• Unit dimension (with stand) - 397mm (W) x 428mm (H) x 423.5mm (D)
• Packed unit dimension (carton) - 460mm (W) x 450mm (H) x 526mm (D) for China, India
446mm (W) x 420mm (H) x 475mm (D) for other regions
• Net weight - 13.5 kg
• Gross weight - 15.8 kg (for China, India)
15.4 kg (for other regions)
5.15 Transportation
Transportation standards refer to UAN-D1534/00 and TYE-M0002
5.15.1 Transportation packages
Packaging and wrapping shall be sufficient to protect the product against damage or loss
during shipment from the supplier to the destination specified in the purchase order. All
packaging materials are subject to test and evaluation per TYE-M0002. The cushion material
shall be constructed using EPS material.
Carton paper (Double wall AB flute corrugate board, colour brown)
Bursting - 19.3 kgf/cm 2 min
Compression - 670 kgf min
5.15.2 Transportation test procedures
The overall test sequence is: vibration test, drop test and when applicable cold drop test. The sequential tests
have to be carried out using the same packaging.
Vibration, drop test should be performed at ambient temperature (20°C to 23 o C) and relative
humidity (40% to 65%).
--- DBC test required and refer to TYE-M0002.
• Transportation test specification for all regions except China/India, refer to UAN-D1534/01
