17” CDT Color Monitor 107B7
74
5.5 Color for resin/paint
Per Philips make-up sheet
5.6 Resins
• RoHS requirements.
• WEEE requirements.
5.7 If paint is used
• RoHS requirements.
• WEEE requirements.
5.8 Plastic mold tooling
• Tooling to be designed to minimize cosmetic defects induced by molding process (sink, blush, weld lines, gate
marks, ejector marks, etc.).
• Painting to cover up cosmetic defects due to molding is strongly discouraged.
5.9 Plastics flammability
• All Plastics expect Base / Pedestal to be Flame Retardant UL 94-V0 or Better (if monitor weighs less than 18kg;
UL94-V0 is OK).
• Base / Pedestal to be Flame Retardant UL 94-HB.
• All major plastic parts (bezel, back cover) need to be molded from same resin. Base / Pedestal otherwise
specified.
5.10 Texture/Glossing of housing
• The texture area and texture no. should follow Philips make-up sheet.
• The exterior surfaces shall have a uniform texture.
• Philips must approve the mold texturing.
• Detail document for texture refer to UAN-D249.
• < = 20 gloss units
5.11 Tilt/Swivel Base ranges
• Tilt Range - Up = 14° ± 1°, Down = 3.5° ± 1°
• Swivel Range - ± 90°
• Base should not break plastic when attempting to rotate it past the stops.
