PIONEER DVD-V7200 Industrial DVD Player RS-232 Command Protocol Manual
- 82 -
Diode Specifications
Forward Voltage Drop (VF)
Less than 0.7 (IF 1ma)
Surge Forward Current (IFSM)
Less than 100ma
Forward Current
Less than 10
µµ
a
9.2.1
Simple Circuit
SW4
SW5
SW6
SW7
SW8
SW3
SW2
SW1
STACK
GROUP 3
STACK
GROUP 2
STACK
GROUP 1
ENTER
RIGHT ARROW
◊
LEFT ARROW
⇓
DOWN ARROW
UP ARROW
