PIONEER DVD-V7200 Industrial DVD Player RS-232 Command Protocol Manual
- 46 -
16 ffH
17 00H Fixed data
18 01H The upper digit of Stack group
19 23H The lower digit of Stack group
20 00H Fixed data
21 01H Fixed data
22 ~
~ ~
Execution :
Command String Status Return DVD-V7200
WU Park mode
R
004c4008...
.001ab6
Receives the command and starts
the transfer of the data, 76 bytes. It
ends with .
R
5.44 Weekly Timer Data Download
Function : Sends the data of the Weekly Timer to the player.
Format : WD
Explanation : The Weekly Timer data is written in the player from the computer after
received the command while it is Park mode.
Refer to the descriptions of Weekly Timer Data Upload.
The Communication flows as follows.
Flow of the communication :
Computer DVD-V7200
---WD--->
<---R----
--1st byte data-->
--2nd byte data-->
~
--75th byte data-->
--76th byte data-->
<---R----
