PIONEER DVD-V7200 Industrial DVD Player RS-232 Command Protocol Manual
- 40 -
2 : Gray
3 : Red
4 : Blue
5 : Green
6 : Yellow
7 : Orange
bit1, 0 : Paint mode
0 : Only frame
1 : The frame with filled color in inside it.
2 : The frame with filled color in outside it.
Format of Blackboard ; Text data in the data :
The length of Blackboard ; Text data is a flexible length, from 22 bytes up to 341
bytes.
Example : Displays the text compulsively.
Title 02, from Frame 3600 to Frame 4800. And GROUP 01, UNIT 03, Text in 3rd
line.
BP Data Explanations
1216 + BARCODE_SRP #n 54H Means “T”, indicates the ID of Picture.
+ 1 04H (1) Display mode ; This is a Forced
display.
+ 2 02H The starting Title number
+ 3 00H The starting Address number (MSB)
+ 4 00H The starting Address number
+ 5 0eH The starting Address number
+ 6 10H The starting Address number (LSB)
+ 7 02H The ending Title number
+ 8 00H The ending Address number (MSB)
+ 9 00H The ending Address number
+10 12H The ending Address number
+11 c0H The ending Address number (LSB)
+12 00H The number of Group
+13 01H The number of Group
+14 00H The number of Unit
+15 03H The number of Unit
+16 00H The starting point of Text (MSB)
+ 17 40H The starting point of Text (LSB)
