Specifications – Panasonic CF-T5 Series User Manual
Page 36
36
Specifications
Getting Started
Usef
ul Inform
ation
Troubleshooting
Appendix
*1
1 MB = 1,048,576 bytes
*2
A segment of the main memory is allotted automatically
depending on the computer’s operating status. The size of
the Video Memory cannot be set by the user.
*3
1 GB = 1,000,000,000 bytes. Your operating system or some
application software will report as fewer GB.
*4
A 16,777,216 color display is achieved by using the dithering
function.
*5
Display may be impossible using some connected external
displays.
*6
When using an external display with a resolution of 2048 x
1536 dots, use a display that supports a 60Hz refresh rate. If
an external display that does not support a 60Hz refresh rate
is used, images may not be displayed properly.
*7
Some devices cannot be used depending on the port type.
*8
For information on TPM, click [start] - [Run] and input
“c:\util\drivers\tpm\README.pdf”, and refer to the Installation
Manual of “Trusted Platform Module (TPM)”.
*9
Operation has been tested and confirmed using Panasonic
SD Memory Cards with a capacity of up to 2 GB.
The transfer rate using the SD Memory Card slot on this
computer is 8 MB per second. (This is a theoretical value,
and differs from actual speeds.)
The transfer rate is 8 MB per second even if you use an SD
Memory Card that supports high-speed transfer rates.
Operation on other SD equipment is not guaranteed.
This computer is not compatible with MultiMediaCards or
SDHC Memory Cards.
Do not insert these kinds of cards.
*10
Only a RAM module designed for DDR2 (PC2-4200) can be
added (Panasonic : CF-BAW0512U, CF-BAW1024U).
JEDEC standard 214 pin Micro DIMM cannot be used.
PC2100 / PC2700 172 pin Micro DIMM cannot be used.
If a PC2-3200 RAM module is installed, the main memory
processing speed may become slower.
*11
Does not guarantee operation of all USB-compatible peripherals.
*12
The AC adaptor is compatible with power sources up to
240 V AC adaptor. This computer is supplied with a 125 V
AC compatible AC cord.
20-M-2-1
*13
Varies depending on the usage conditions, or when an
optional device is attached. Measured when the power saving
function on the USB2.0 USB Root Hub is set to on. (At the
time of purchase, the power saving function is activated.)
When Economy Mode (ECO) is enabled, the operating time
becomes approximately 20% shorter than when it is disabled.
*14
Measured using BatteryMark
™
Version 4.0.1 (LCD bright-
ness : Maximum - Minimum).
*15
Measured using MobileMark
™
2005 (LCD brightness : 60
cd/m
2
).
*16
Varies depending on the usage conditions, CPU speed, etc.
It may take a long time to charge a fully discharged battery.
*17
Approx. 1.5 W when the battery pack is fully charged (or not
being charged) and the computer is off.
*18
Rated power consumption.
23-E-1
*19
Average value. May differ depending on models.
*20
Operations of this computer are not guaranteed except for
the pre-installed OS.
*21
Must be installed before use.
*22
The Product Recovery DVD-ROM is required.
*23
For startup methods, refer to “Hardware Diagnostics”
(Î page 31).
*24
These are speeds specified in IEEE802.11a+b+g stan-
dards. Actual speeds may differ.
Pre-installed Software
*20
Microsoft
®
Internet Explorer 6 Service Pack 2 / DirectX 9.0c /
Microsoft
®
Windows
®
Media Player 10 / Microsoft
®
Windows
®
Movie Maker 2.1 /
Microsoft
®
.NET Framework 1.1 SP1/2.0 / Adobe Reader / Intel
®
PROSet/Wireless
Software
/ Touch Pad Utility / DMI Viewer / PC Information Viewer / Bluetooth™ Stack for Win-
dows
®
by TOSHIBA
Settings / Wireless Switch Utility tooth> / Economy Mode (ECO) Setting Utility / Battery Recalibration Utility / Infineon *21 / Recover Pro 6 *21 Setup Utility / Hard Disk Data Erase Utility *22 / PC-Diagnostic Utility *23 Model No. CF-T5LWETZBM Wireless LAN Data Transfer Rates IEEE802.11a: 54/48/36/24/18/12/9/6 Mbps (automatically switched) *24 IEEE802.11b: 11/5.5/2/1 Mbps (automatically switched) *24 IEEE802.11g: 54/48/36/24/18/12/9/6 Mbps (automatically switched) *24 Standard Supported IEEE802.11a/IEEE802.11b/IEEE802.11g Transmission Method OFDM system, DS-SS system Wireless Channels Used IEEE802.11a: Channels 36/40/44/48/52/56/60/64/149/153/157/161/165 IEEE802.11b/ IEEE802.11g: Channels 1 to 11 RF Frequency Band IEEE802.11a: 5.18 - 5.32 GHz, 5.745 - 5.825 GHz IEEE802.11b/ IEEE802.11g: 2412 - 2462 MHz Bluetooth™ Bluetooth Version 2.0 + EDR Transmission Method FHSS system Wireless Channels Used Channels 1 to 79 RF Frequency Band 2.402-2.48 GHz 07_Appendix_T5mk2.fm Page 36 Thursday, December 7, 2006 10:31 AM
TPM Professional Package V2.5
