Set-up Menus
TIME CODE menu
Item
No. S u p e r i m p o s e d
d
d i s p l a y
y
500 VITC POS-1
501 VITC POS-2
502 VITC BLANK
503 TCG REGEN
504 BINARY GP
505 TCG CF FLAG
506 DF MODE
507 TC MODE
508 TC PRESET
509 UB PRESET
No.
0000
0001
0006
0010
0000
0001
0008
0010
0000
0001
0000
0001
0002
0000
0001
0002
0003
0004
0005
0006
0007
0000
0001
0000
0001
0000
0001
0002
0003
Setting
S u p e r i m p o s e d
d
d i s p l a y
y
Description of settings
10L This sets the position where the VITC signal is to be
1 1 L inserted.
: (The same line as that selected for VITC POS-2 cannot
16L be selected.)
:
20L
10L This sets the position where the VITC signal is to be
11L inserted.
: (The same line as that selected for VITC POS-1 cannot
18L be selected.)
:
20L
BLANK This sets whether the VITC signal is to be output.
THRU 0: VITC signal is not output.
1: VITC signal is output.
TC UB This selects the signal to be regenerated when the
TC TCG is in the REGEN mode. (item No. 507)
UB 0: Both the time code and user
’
s bit are regenerated.
1: Only the time code is regenerated.
2: Only the user's bit is regenerated.
’
s bit is regenerated.
000 This sets the status for using the user's bit of the time
’
s bit of the time
001 code generated by the TCG.
010 0: NOT SPECIFIED (character set is not used)
011 1: ISO CHARACTER (8bit character set complying
100 with ISO646 and ISO2022 is used)
101 2: UNASSIGNED-1 (not defined)
110 3: UNASSIGNED-2 (not defined)
111 4: UNASSIGNED-3 (not defined)
5: PAGE/LINE (SMPTE262M page/line multiplexing
system)
6: UNASSIGNED-4 (not defined)
7: UNASSIGNED-5 (not defined)
OFF This selects whether the CF flag of the TCG is to be set
ON ON.
0: CF flag is set OFF.
1: CF flag is set ON.
DF This selects the drop frame or non-drop frame mode for
NDF CTL and TCG.
0: CTL and TCG are used in the drop frame mode.
1: CTL and TCG are used in the non-drop frame mode.
P-REC
This sets the TCG mode.
P-FREE
0: Internal TC PRESET is used in the REC RUN mode.
I-REGEN 1: Internal TC PRESET is used in the FREE RUN
E-VITC mode.
2: Internal TC is used in the REGEN mode.
3: VITC of input video signals is used in the REGEN
mode.
This sets the time code generator value.
This sets the user
s bit value.
The underlined number and item are the factory settings.
