Recommended Configuration
Use dedicated SWA500 amplifier to achieve optimal performance as recommended by Polk Audio (see note on SPEX Cards under SWA500).
Factory Support
For product support, contact our service department at 1-800-377-7655 9am to 6pm EST, Monday-Friday,
or contact Customer Service at [email protected]
For more information on the CSW200 and specific installation procedures, log onto
http://www.polkaudio.com/downloads/manuals/home/CSW100_200_Manual.pdf
CSW200 shown with aftermarket 12" x 12" floor grate.
P E R F O R M A N C E
DRIVER COMPLEMENT SINGLE LONG-THROW KLIPPEL-ANALYZED 10-INCH DRIVER
POWER HANDLING (WATTS) 250 CONTINUOUS
OVERALL FREQUENCY RESPONSE 22HZ-140HZ
LOWER -3DB LIMIT 28HZ
UPPER -3DB LIMIT 120HZ
NORMAL IMPEDANCE 8 OHMS
C O N N E C T I O N S
SPEAKER WIRE
MAXIMUM WIRE SIZE ACCOMMODATED 12 AWG
MINIMUM RECOMMENDED 18 AWG
INPUT CONNECTORS HEAVY-DUTY SPRING LOADED PUSH
TERMINALS, ONE PAIR PER SIDE
IMPORTANT NOTE: The CSW200 is equipped with two sets of binding posts for
installing convenience. Use either set to hook up the subwoofer to the ampli-
fier. Do not use both sets. Always use one set.
Specifications
