10 P o l k A u d i o C u s t o m I n s t a l l P r o d u c t : M o d e l N u m b e r
SWA500
High Performance Subwoofer Amplifier
Hybrid Class D amplifier, producing 250W Continuous Power into 8 Ohms and 500W Continuous Power into 4 Ohms.
Dimensions
Chassis
3 1/2" H x 17" W x 12 5/8" D (8.89 cm H x 43.18 cm W x 32.07 cm D)
17”
43.18cm
3 1/2”
8.89cm
W E I G H T
INSTALLED WEIGHT 9.8 LBS. (4.5 KG.)
SHIPPING WEIGHT 17 LBS. (7.7 KG.)
P E R F O R M A N C E
POWER CONTINUOUS 250W INTO 8 OHMS
500W INTO 4 OHMS
POWER PEAK 800W
BANDWIDTH 15HZ - 250HZ
DISTORTION 0.01%
CROSSOVER FREQ RANGE 40HZ - 120HZ
CROSSOVER SLOPE 24dB/OCT
POWER REQUIREMENTS 120V 60HZ AC, 6.3 AMPS
AVAILABLE IN 220V? YES
P R O T E C T I O N C I R C U I T R Y
The SWA500 amplifier offers dynamic power control, thermal protection,
short circuit, fuse and over-current protection.
A C C E S S O R I E S
SPEX Cards, which configure EQ, Crossover and Power Control circuitry to
each Polk subwoofer.
Rack ears
C O N N E C T I O N S
SPEAKER WIRE
MAXIMUM WIRE SIZE ACCOMMODATED 12 AWG
MINIMUM RECOMMENDED 18 AWG
SPEAKER OUT/SPEAKER IN 5-WAY BINDING POSTS
LINE IN/OUTPUTS LFE, LINE IN L/R, LINE OUT L/R
POWER CONNECTIONS 8 FOOT DETACHABLE IEC POWER CORD
4”
10.16cm
(with
feet)
