6 P o l k A u d i o C u s t o m I n s t a l l P r o d u c t : M o d e l N u m b e r
Recommended Configuration
Use dedicated SWA500 amplifier to achieve optimal performance as recommended by Polk Audio (see note on SPEX Cards under SWA500).
Factory Support
For product support, contact our service department at 1-800-377-7655 9am to 6pm EST, Monday-Friday,
or contact Customer Service at [email protected]
For more information on the CSW155 and specific installation procedures, log onto
http://www.polkaudio.com/downloads/manuals/home/CSW100_155_200_Manual.pdf
P E R F O R M A N C E
DRIVER COMPLEMENT SINGLE LONG-THROW KLIPPEL-ANALYZED 10-INCH DRIVER
OVERALL FREQUENCY RESPONSE 30HZ-140HZ
LOWER -3DB LIMIT 36HZ
UPPER -3DB LIMIT 120HZ
NORMAL IMPEDANCE 8 OHMS
C O N N E C T I O N S
SPEAKER WIRE
MAXIMUM WIRE SIZE ACCOMMODATED 12 AWG
MINIMUM RECOMMENDED 18 AWG
INPUT CONNECTORS HEAVY-DUTY SPRING LOADED PUSH
TERMINALS, ONE PAIR PER SIDE
Specifications
