Panasonic WV-NM100 - Manual (Page 19)

19
The "Network" window appears.
If the “TCP/IP” item is not displayed, refer to the operating
instructions of the OS and follow the procedures to install the
TCP/IP.
The "TCP/IP Properties" window appears.
Screenshot 4
Note
Screenshot 3
Click the [Configuration] tab.
Click to select the TCP/IP protocol of the cur-
rently used network card.
Click the [Properties] button.
STEP5
STEP4
STEP3
Click the [IP Address] tab.
Click the "Specify an IP address" radio button.
Enter the IP address and the subnet mask as
follows.
• IP Address: 192.168.0.9
• Subnet Mask: 255.255.255.0
Click the [OK] button, and the window closes.
Restart the PC to make the IP address valid.
STEP10
STEP9
STEP8
STEP7
STEP6
