13

Using with an Intranet (LAN)

(Connection type 2)

Connect the camera to an intranet (LAN) using an Ethernet switching hub or router when browsing camera pictures
of a camera installed in the same LAN (the intranet of a company or home).

< Connection example >

< Required hardware >
Ethernet switching hub or router

< Required cable >
Ethernet cable (category 5 straight cable)

• Use an Ethernet switching hub or router suitable for 10Base-T/100Base-TX.
• Install also a LAN card suitable for 10Base-T/100Base-TX on the PC.
• All cameras connected to the network must use their own exclusive AC adapter.

! Important

Ethernet
switching hub or router

LAN

AC adapter

To an outlet
(120 V AC)

AC adapter

To an outlet
(120 V AC)
