11
INSTALLATIONS
This is an example of an installation onto a wall.
Screws
Wall-mounting bracket
Install the wall-mounting bracket onto the wall
using the screws.
STEP1
Install the camera onto the wall-mounting brack-
et by referring to the illustration shown on the
left.
It is possible to install the camera upside down.
Install the camera in the upside down position
according to your needs.
Confirm that the Panasonic logo is in the posi-
tion shown in the illustration.
If the logo is upside down, rotate the logo.
STEP3
STEP2
Logo
If the camera is placed on a desk, as shown in the illustra-
tion on the right, select "Desk top" for "Camera position" on
the "Basic setup" page.
Note Logo
