2010 Sep 13 6
NXP Semiconductors Product specification
Silicon MMIC amplifier BGA2003
handbook, halfpage
0 10 15 25
gain
(dB)
25
0
20
MGS544
5 20
15
10
5
IVS-OUT (mA)
Gmax
GUM
Fig.10 Gain as a function of the bias current
(I
VS-OUT
); typical values.
V
VS-OUT
= 2.5 V; f = 1800 MHz.
handbook, halfpage
0
MGS545
10 2 10 3 10 4
10
20
30
40
gain
(dB)
f (MHz)
MSG
Gmax
GUM
Fig.11 Gain as a function of frequency; typical
values.
V
VS-OUT
= 2.5 V; I
VS-OUT
= 10 mA.
handbook, halfpage
3
0
MGS546
1 10 10 2
1
1.5
0.5
2
2.5
NFmin
(dB)
IVS-OUT (mA)
(3)
(2)
(4)
(1)
Fig.12 Minimum noise figure as a function of the
bias current (I
VS-OUT
); typical values.
(1) f = 2400 MHz.
(2) f = 1800 MHz.
(3) f = 1000 MHz.
(4) f = 900 MHz.
