2010 Sep 13 4
NXP Semiconductors Product specification
Silicon MMIC amplifier BGA2003
handbook, halfpage
MGS536
100 pF R1
C
C
RF in
RCTRL
VCTRL
RF out
VS
1
4 3
2
BGA2003
L1
Fig.2 Typical application circuit.
handbook, halfpage
0 50 100 200
200
150
50
0
100
MGS537
150
Ts (
°
C)
Ptot
(mW)
Fig.3 Power derating.
handbook, halfpage
0 0.5 1 2
2.5
0
2
MGS538
1.5
1.5
1
0.5
VCTRL (V)
ICTRL
(mA)
Fig.4 Control current as a function of the control
voltage on pin 3; typical values.
I
CTRL
= (V
CTRL
− 0.83)/296.
handbook, halfpage
0 2.5
30
0
10
20
MGS539
0.5 1 1.5 2
IVS-OUT
(mA)
ICTRL (mA)
Fig.5 Bias current as a function of the control
current; typical values.
V
S-OUT
= 2.5 V.
